    MPF Biodrum 50 Small

    Koi-vijvers tot 30m3
    Product description
    The Makoi CombiDrum 50 small has a capacity to pump 25m3 per hour, and is suitable for koi ponds up to 30m3 and swimming ponds of 60m3 The Screen is a 70micron that has an extremely high water contact surface of over 80%! The waste chute consists of a sloping waste with 110mm connection. This is also available with flush function. The Biokamer...

    The Makoi CombiDrum 50 small has a capacity to pump 25m3 per hour, and is suitable for koi ponds up to 30m3 and swimming ponds of 60m3

    • The Screen is a 70micron that has an extremely high water contact surface of over 80%!
    • The waste chute consists of a sloping waste with 110mm connection. This is also available with flush function.
    • The Biokamer has a capacity of 225 liters for the moving bed material.
    • An industrial motor was chosen that moves the drum around. Very reliable and very strong, up to 210Nm !!
    • Filter comes standard with lid.

    Specifications Biodrum 50

    The sizes of the inputs and outputs can be modified to customer wishes.

    Drum dimensions: diameter 420mm, length is 400mm.
    Maximum flow: 25m3 per hour with maximum water level.
    Control: Incl. with dry run protection

    Incl. Air disk
    Incl. industrial drum control
    Incl. Bypass for emergencies.
    Incl. internal Flushing pump
    Incl. Lid

    The filter comes standard with a 2-year warranty (excluding filter cloth)





    DOWNLOAD DRAWING

    Product specifications

    MAX. FLOW M3/HOUR
    25
    INLET (MM)
    3x110
    OUTLET (MM)
    2x110
    Advice max. Volume koi pond (m3)
    50
    Advice max. Volume swimmingpond/pool (m3)
    100
    Material
    Polypropylen
