    MPF Biodrum 50 Small

    Koi-vijvers tot 30m3
    Product description
    The Makoi BioDrum 50 small has a capacity to pump 25m3 per hour, and is suitable for koi ponds up to 30m3 and swimming ponds of 60m3 The Screen is 70micron that has an extremely high screen to water conatct ratio of over 80%! The gutter consists of a sloping PP construction with 110mm connection. This is also available with flush function. The...

    The Makoi BioDrum 50 small has a capacity to pump 25m3 per hour, and is suitable for koi ponds up to 30m3 and swimming ponds of 60m3

    • The Screen is 70micron that has an extremely high screen to water conatct ratio of over 80%!
    • The gutter consists of a sloping PP construction with 110mm connection. This is also available with flush function.
    • The Biochamber has a capacity of 225 liters for the movingbed material.
    • An industrial motor was chosen that moves the drum around. It is Very reliable and very strong, The power of the motor goes up to 210Nm !!
    • Filter comes standard with lid.

    Specifications Biodrum 50

    The sizes of the inputs and outputs can be modified to customer wishes.

    Drum dimensions: diameter 420mm, length is 400mm.
    Maximum flow: 25m3 per hour with maximum water level, and in gravity.
    Control: Incl. with dry run protection

    Incl. Air disk
    Incl. industrial drum control
    Incl. Bypass for emergencies.
    Incl. internal Flushing pump
    Incl. Lid

    The filter comes standard with a 2-year warranty (excluding filter screen)

    Download Drawing










    Product specifications

    SKU
    B50S
    MAX. FLOW M3/HOUR
    25
    INLET (MM)
    3x110
    OUTLET (MM)
    2x110
